1. FN key combination and lighting control instructions
2-1. FN Composite Multimedia
FN + F1= Music
FN + F2= sound -
FN + F3= sound +
FN + F4 = Mute
FN + F5 = stop
FN + F6= previous song
FN + F7= Play/Pause
FN + F8= next song
FN + F9 = mail
FN + F10=Home
FN + F11=My Computer
FN+F12=Calculator
2. RGB LED color control (make sure the light is on)
FN+PGDN: Turn off/on the light, if you need to switch the light effect after turning off the light, you need to turn on the light first (factory enabled)
FN+1: The red light is always on.
FN+2: The green light is always on.
FN+3: The blue light is always on.
FN+4-8: Customize light mode.
FN+PGUP: light recording/storage
After pressing FN+4 to 8 to enter the corresponding combination mode, press FN+PGUP to enter the custom recording state
Press the same button continuously to the specified color, and then continue to set other buttons. After the setting is completed, press FN+PGUP to save. After entering the recording state, the CapsLock and indicator lights will continue to flash to prompt, and the recording light OK indicator will flash and turn off when the recording is completed, and the state before recording will be restored.
FN+Ins light effect switching, a total of 19 backlight effects;
FN+Del seven-color single-color switching of lighting, with FN+Ins to get more lighting effects
FN + ↑ direction key to brighten; (the Caps Lock light flashes when it is adjusted to the brightest)
FN+↓direction key dimming; (the Caps Lock light flashes when adjusted to the weakest)
FN + ← arrow keys light slow down (the Caps Lock light flashes when adjusted to the slowest)
FN+→direction key light acceleration; (Caps Lock light flashes when adjusted to the fastest)
3. Keyboard mode switching operation and indicator light description
Located on the upper left side of the keyboard, there is a three-position toggle switch near the ESC key and a two-position toggle switch near the F1 key.
3-1. When the three-stage switch is turned to the left, the keyboard switches to 2.4G mode
After the toggle switch is switched to 2.4G RF mode (the 2.4G indicator light is on), short press FN+R to enter the corresponding 2.4G reconnection state, and the blue light of the corresponding button flashes slowly to indicate that it is connected or timed out, and the blue light is off. Press and hold for more than 3s to enter the corresponding pairing state (factory paired), the red light of the corresponding button flashes quickly to indicate that it is connected or timed out, and the red light is off.
3-2. When the three-stage switch is turned to the middle, the keyboard switches to wired mode
After the toggle switch is switched to USB mode, the battery is charged through the TYPE-C data cable (the red light of the battery indicator is on), the red light is off and the green light is on when the battery is fully charged.
4. Knob. Mode switching operation
The knob in the upper right corner, the factory mode is A mode, press the knob to switch between AB;
A mode: backlight brightness adjustment (default)
B mode: volume increase and decrease
Knob control description:
The factory setting knob is turned to the left to decrease the brightness (equivalent to FN+↓), to the right to increase the brightness (equivalent to FN+ up), the brightness is not locked, and the brightness returns to the default brightness after switching the light (the default is high brightness);
When the knob switch is pressed, the switch knob rotates to volume - (to the left), volume + (to the right), and the knob switch is a mode switching switch for brightness adjustment/volume adjustment;
5. System and working voltage and current
Mac OS X10, 12, iOS10 or later
Voltage: 5V
Current: 200MA (the brightest backlight)/20MA (turn off the backlight)
sleep
After the wireless keyboard is connected to the device, it will enter sleep mode without operation for 1 minute, and click any key to wake up the original state..
